BG Running Tool
The Rebco BG Running Tool is a locating and running tool purpose-built for positioning sub-surface accessories equipped with ROTS-1 or ROTS-2 Lock Sub-Assemblies into their corresponding selective seal profiles within the wellbore. Its primary function is not to set the device by jarring, but to accurately locate a specific seal profile among several within a multi-nipple completion string, a critical distinction in selective completions, where the wrong profile must not be accidentally engaged.
The BG operates by engaging the collet or locating feature of the Lock Sub-Assembly against the correct profile recess as the tool string is lowered. Once the proper profile is located and the accessory is seated, the running tool is released and retrieved, leaving the sub-surface device locked in place. This makes the BG an essential tool in gas lift, chemical injection, and other multi-zone selective applications where precise depth control and profile selectivity are paramount.
How to Order: Available in assembly numbers 4101052370 (2⅜"), 4101052870 (2½"), 4101053500 (3½"), and 4101054500 (4½"). Specify nominal size when ordering
